E-mtb Crank Upgrade. Performance Value.
Helix Core e*spec cranks give your e-bike an upgrade with high-end integrity and aesthetics at a great value. Engineered for e-MTB strength, so you don’t need to worry about pedal strikes or holding back on your next gravity run. Forged aluminum arms keep you confident on the trail, while alloy self-extracting crank bolts mean efficient routine service, and minimum added weight. Added details like pedal washers, molded impact boots, and e-rider preferred shorter lengths deliver all the high-end features you'd expect from a crankset well over its price.
Chainline
Available in 24mm ISIS (21.5 and 26mm offsets) for Bosch CX Gen4/SX, Brose, TQ HPR50, Yamaha, and 30mm (18.5mm offset) for Fazua Ride 60.
Chainring
Helix Race E*spec Chainring, Helix Core Steel Chainring, e*spec Plus rings, 104BCD spider, or other rings designed to fit Bosch G4, Brose S Mag, or TQ HPR50
(sold separately)
Color
Black
Compatibility
Compatible with Bosch, Brose S Mag, TQ HPR 50, and Fazua Ride 60
Included
Crankset, Crank Boots (x2), Sticker, User Manual
Length
155mm, 160mm, 165mm, 170mm
Material
Forged AL-6066-T6 arms
Spindle
Compatible with 24mm and 30mm ISIS Spindles
Weight
24mm | Bosch | Brose | TQ Model Weights
155mm: 481g
160mm: 497g
165mm: 513g
170mm: 529g
30mm | Fazua Model Weights
155mm: 448g
160mm: 463g
165mm: 478g
170mm: 493g
